Ortal Corner 51H (130H)LS/RS

Wide or narrow, cozy or imposing, Ortal’s left-side or right-side natural gas corner fireplace collection is ideal and flexible architectural solution that bring focus to any space. Enjoy the modern luxury of a direct vent fireplace equipped with Ortal’s revolutionary cooling technology, which keeps the surrounding temperature down while retaining the heat-producing properties of a traditional fireplace.

Hidden
Hidden
Name(Required)
Address

Specifications

  • Viewing Area:53″ W X 21 5/8″ H
  • Weight Double Glass/Weight Screen: 317 LBS/295 LBS
  • Fuel Type:LPG, NG
  • LPG BTU Output/LPG Efficiency: 35,316/81.40%
  • NG BTU Output/NG Efficiency : 37,167/77.80%
  • Vent: 5X8 CO-AXIAL DIRECT VENT PIPE (5-INCH INTERIOR, 8-INCH EXTERIOR)
  • Heat Barrier: Double Glass, Micro Mesh Screen
  • Interiors: Black Reflective Glass, Blackridge
  • Controls: REMOTE, WALL SWITCH

Advantages & Benefits

  • Passive Cool Wall Technology
  • Creative Interiors
  • Heat Barrier Solutions
  • Power Vent System
  • Lighting
  • Direct Vent
  • Efficiency
  • SmartHome

Downloads

Manual:Ortal Installation Manual – Evolve 51 Series (V1.0)

Framing and Clearances:51H Corner Framing

Double Glass Left Side:51H LS (DG) (1)

Screen Drawing Left Side:51H LS (Screen) (1)

Double Glass Right Side:51H RS (DG) (1)

Screen Drawing Right Side:51H RS (Screen) (1)

Product Brochure:Ortal Catalog – 2022 Full Line
